Solar Panels

Features

1. Core component for on-grid and off-grid solar power systems, suitable for caravans, RVs, boats, greenhouses, and other solar installations.

2. Easy installation with pre-drilled mounting holes. Each solar panel is supplied with a 90 cm 12AWG cable and MC4 male/female quick connectors.

3. Bypass diodes minimize power loss caused by shading.

4. IP65 waterproof junction box – advanced protection against dust and low-pressure water jets, ensuring reliable outdoor performance.

5. Resistant to salt corrosion and high humidity, ideal for marine and coastal environments.

6. Corrosion-resistant aluminum frame designed for long-term outdoor use. Built to last up to 25 years, capable of withstanding high wind loads (2400 Pa) and snow loads (5400 Pa). Lightweight anodized aluminum frame combined with 3.2 mm tempered, patterned, anti-reflective glass for enhanced safety and efficiency.

Solar Panel Specifications

• Rated Power: 120W

• Operating Voltage (Vmp): 18.15V

• Open Circuit Voltage (Voc): 21.78V

• Short Circuit Current (Isc): 6.93A

• Operating Current (Imp): 6.6A

• Output Tolerance: ±5%

• Maximum System Voltage: 1000V DC (IEC) / 600V DC (UL)

• Diodes: 2 bypass diodes

• Junction Box Rating: IP65

• Operating Temperature Range: −40°C to +80°C

• Frame Material: Heavy-duty solid aluminum alloy

• Glass Type: 3.2 mm tempered glass

• Output Cable: 2.5 mm², 90 cm (0.09 × 3.54 inches)

• Dimensions: 1045 × 550 × 25 mm

• Weight: 6.5 kg

Compact & Reliable Performance

The 120W 18V monocrystalline solar panel delivers a stable average output of up to 600Wh per day, depending on sunlight availability. Its compact solar cell design ensures efficient energy generation while maintaining a lightweight and durable structure.
